Auxiliary Cables Pack
Get Bus Pirate & Accessories
Contents
| Quantity | Cable | Length | Description |
|---|---|---|---|
| 1 | Logic analyzer cable | 15cm | 9pin 1.0mm to 9*1pin 2.54mm |
| 2 | Grey silicone Y splitter | 15cm | 1pin 2.54mm to 2*1pin 2.54mm |
| 1 | Red silicone Y splitter | 15cm | 1pin 2.54mm to 2*1pin 2.54mm |
| 1 | Black silicone Y splitter | 15cm | 1pin 2.54mm to 2*1pin 2.54mm |
| 8 | Grey silicone jumper | 15cm | 1pin 2.54mm to 1pin 2.54mm |
| 1 | Red silicone jumper | 15cm | 1pin 2.54mm to 1pin 2.54mm |
| 1 | Black silicone jumper | 15cm | 1pin 2.54mm to 1pin 2.54mm |
Packaging
| Quantity | Item | Description |
|---|---|---|
| 1 | 1cm Velcro cable tie | 5cm |
| 1 | Zipper Bag | 7x10cm |
| 1 | T Box | 7x7x2cm (5.5x6.5x1.5cm inner) |
| 1 | Label Wrap | ‘A’ |
- Wrap the AUX cables with 5cm of Velcro cable tie
- Place the cables in a bag
- Place the bags in a box
- Seal the box with a wrap label
- Shrink wrap the box
EAN Number
| EAN | Contents | Version |
|---|---|---|
| 6098403367381 | Auxiliary Cables | REV0 |
| TDB | Auxiliary Cables (color coded crimp housings) | REV1 |
